تفاصيل المنتج:
شروط الدفع والشحن:
|
| اسم المنتج: | حاجز شوشين الملحوم | المعالجة السطحية: | المجلفن بالغمس الساخن |
|---|---|---|---|
| مواصفة: | ميل 1 | لون التكسية الأرضية: | الأخضر العسكري |
| مخزون: | 1000 قطعة | طَرد: | البلاستيك ثم البليت |
| يستخدم: | السيطرة على الفيضانات الجدار | اسم: | Mil 1 حاجز دفاعي قابل للطي جدار أمني مجلفن حاجز دفاعي للفيضانات انفجار حاجز حاجز ملحوم |
| إبراز: | galvanized folding security barrier,sand filled flood defensive wall,welded explosion retaining bastion,sand filled flood defensive wall,welded explosion retaining bastion |
||
Mil 1 Folding Defensive Barrier Galvanized Security Wall Flood Defensive Barrier Explosion Retaining Wall Welded Bastion
operational principle
Defensive barrier wall is a prefabricated,multi-cellular system, made of zinc coated steel welded mesh and lined with non-woven geotextile. Units can be extended and joined using the provided joining pins. It is easy installed with using minimal manpower and commonly available equipment. After extended, it is filled into sand,stone,like a defence wall or bunker,it is widely used for fortification and flood control.
Quick Details
| Unit Type |
Height (M) |
Width (M) |
Length (M) |
Internal Cells |
| SX-01 | 1.37 | 1.08 | 10 | 9 |
| SX-02 | 0.61 | 0.61 | 1.22 | 2 |
| SX-03 | 1.0 | 1.0 | 10 | 10 |
| SX-04 | 1.0 | 1.5 | 6 | 6 |
| SX-05 | 0.61 | 0.61 | 3.05 | 5 |
| SX-06 | 1.68 | 0.61 | 3.05 | 5 |
| SX-07 | 2.21 | 2.13 | 8.25 | 4 |
| SX-08 | 1.37 | 1.22 | 10 | 9 |
| SX-09 | 1.0 | 0.76 | 6.84 | 9 |
| SX-10 | 2.13 | 1.52 | 7.6 | 5 |
Detail Specification
1. Wire diameter: 4-5mm
2. Mesh size: 75x75mm,50x50mm
3. Panel size: 12 type size for any security protection,suddenly burst attacks
4. Geotextile: in heavy duty non-woven polypropylene;
5. Color:Grey and Military Green,Sand color etc.
6. Finish: hot dipped galvanized, Galfan wire.
7. Packing: wrapped with shrink film or packed in pallet
| Material | Galvanized steel wire or zinc-aluminum alloy steel wire |
| Mesh Size | 50*50mm, 75*75mm, 76.2*76.2mm, 100*100mm, ect. |
| Wire Diameter | 4mm-6mm |
| Geotextile | 2mm thick, khaki/green, can vary according to different environments |
| Geotextile color | White, beige, Military Green and other customized colors |
|
|
Material: Galvanized steel wire or Galfan/ zinc-5%aluminum wire Service Life: 15-20 years Price:19.8$-99.8$/set Wire diameter: 3.0mm- 6.0mm Aperture:50*50mm 75*75mm 76.2*76.2mm 80*80mm 100*100mm etc Color of geotextile:Grey and Military Green,Sand color etc Gram Weight of geotextile:200g/m2 or 300g/m2 Finish:hot dipped galvanized,Galfan wire. Welded method:welded after galvanized or galvanized after welded Packing:Wrapped with shrink film then packed in wood pallet or iron pallet |
Features
1. having a Galfan coated steel mesh framework
2. integrated cells to provide internal structural integrity.
3. exceptional strength and structural integrity
4. High tensile and anti-impact capability
5. making transportation efficient and rapid
